BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour)

BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour)
BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour)
BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour)

Imagem Grande :  BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour)

Detalhes do produto:
Lugar de origem: China
Marca: BBT
Certificação: ISO9001
Número do modelo: QTQP-1
Condições de Pagamento e Envio:
Quantidade de ordem mínima: 1 conjunto
Preço: referce for price list
Detalhes da embalagem: Cortador de tijolos de barro totalmente automático por remessa marítima de contêiner
Tempo de entrega: 15 dias
Termos de pagamento: L/C, T/T, Western Union
Habilidade da fonte: 10 conjuntos por mês
Contato

BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour)

descrição
Cortador: Sistemas de corte de tijolos de argila de alto desempenho BBT para linha de produção de fabricação d tamanho de corte: Personalizado
Tipo de tijolo adequado: tijolo maciço, blocos ocos, painel de parede, cerâmica Grau de automação: Totalmente Automático
B. Tecnologia Central: Fio vs. Lâmina Linha de tijolos: E. Sistemas de corte na linha de produção para fabricação de tijolos de barro
Destacar:

clay brick cutting machine

,

high performance brick cutter

,

brick making production line equipment

BBT High Performance Clay Brick Cutting Systems for Clay Brick Making Production Line

BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 0



BBT Brick Making Cutting System – Key Component for Clay Brick Production

The cutting systems from BBT are one of the critical parts in the production line of the clay brick making.

They are designed to cut the continuous columns first and then cut the columns into green bricks, the green bricks are ready for drying and firing. Most of the cuttting systems are custom building and BBT can do the design, manufacturing and supplying at the same time.

BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 1



A. The Extrusion & Cutting Workflow

1. Extrusion: The continuous column is extruded from an extruder by a mould.

2. Cutting: Columns will be cutting into different models of green bricks.



BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 2





B. Core Technology: Wire vs. Blade

Wire Cutting: high-tensile steel wires for efficient cutting and desilting.



BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 3



C. Types of cutting systems

BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 4



By Cutting Mechanism:

Vertical Cutter: Cuts designed in vertical to save space, using in high-capacity of brick factories.

Downward Press Cutter: Cuts by pressing down from top to bottom of the columns with high precision and adaptability.

Synchronous Cutter: Featured with a moving frame that matches the extruder's speed for distortion-free cuts.

Multi-Wire Cutter: multiple wires for high-capacity cutting.



BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 5



Automatic level

Fully Automatic, High-speed, high-capacity cutting systems



Cutting systems

Chamfering device: a chamfering knife is installed to bevel edges in the same operation.

Logo printing device: a logo printing device is installed for printing the logo on the side of the bricks.



D. How to Choose a Cutting System



Production capacity: brick capacity from 5,000 bricks to 20,000 bricks/hour;

Automation degree: Fully automatic or half automatic;

How many types of bricks will be cutting: clay solid bricks, clay hollow blocks, facing bricks and pavers;

Precision Requirements: Precision is critical for modern construction standards.

Total investment in the cutting systems:



E. Cutting systems in the production line for clay brick making



BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 6



BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 7



BBT Fully Automatic Clay Brick Cutting Machine with Customizable Cutting Size and High Capacity (5,000-20,000 bricks/hour) 8



BBT Clay Brick Cutting System of Technical datas:

Item Details
Product Name BBT Clay Brick Cutting System
Automation Fully Automatic
Cutting Size Customizable
Suitable Bricks Solid Brick, Hollow Block, Wall Panel, Ceramics
Core Technology Wire Cutting / Blade Cutting
Cutting Types Vertical, Downward Press, Synchronous, Multi-Wire
Capacity 5,000–20,000 bricks/hour
Custom Service Design, manufacturing & supply
MOQ 1 set
Delivery Time 15 days



BBT is a professional provider of full automatic clay brick making production lines and related equipment.

Our main products include:

TCNL series full steel chain box feeder

TWGD series double shaft mixer

GS series roller crusher

TRA series double tooth roller crusher

TWJH series front grid extruding mixer

TWPM series wet pan mill

QTQG series cutter

EV series vacuum extruder

Robot setting machine

Spare parts for brick making machinery

We also offer one-stop solutions for automatic clay brick production projects, covering project design, construction, and comprehensive technical support.
